Features:
1.High precision and high sensitivity
2.Good heat resisting circulation
3.Thermistor chip can be encapsulated in glass
4.Stainless steel tubes are available in a variety of sizes
5.Wide range of temperature measurements
Applications:
1.Beer brewing equipment, household appliances, rice cooker, heater, soybean milk machine, coffee machine,dryer, burner, dishwasher, disinfecting machine, washing machine
2.Refrigerator, air conditioner, electric water heater, freezer, cell phone battery, charger, induction cooker,bread maker, disinfection cabinet, electric oven
3.Automobile, electric vehicle, automobile temperature control system, medical equipment, new temperature measurement, communication equipment
4.Granary temperature measurement, fire alarm, food storage, ocean, deep well, glacier temperature measurement, military and other fields.
Dimensions:
Parameters Characteristics：
1.Thermal reaction time：≤15 seconeds in water bath
2.Dissipation factor: about 2.8mW/℃ in standing air
3.Withstand voltage test：AC 1800V 2mA 1 second
4. Insulation test：≥100MΩ
5. Rated power：≤10mW
6. Operating temperture range：-0℃～100℃
Ordering Instructions：
Please inform the following parameters when ordering NTC temperature sensor:
1、Resistance value requirements (can be selected according to the above table)
2、B value requirements (can be selected according to the above table)
3、Working environment (whether waterproof, moisture-proof, cold and other requirements )
4. Application: different usgae has different temperature resistant wire and different resistance value
5. Operating temperature range
6. Accuracy requirement (1%-5% optional)
7. Shell material (copper, brass, stainless steel, ABS, epoxy resin and so on)
8. Customized shell dimensions is welcome
9. Customized wire rod and length is welcome
10. If connectors are needed at the end of the wire(Molex, JST, CJT and others are optional).
We are a professional manufacturer of NTC thermistors and temperature sensors. The products involve many parameters and specifications,
please confirm before place an order.
R-t table of conventional resistance values:
