Features:
1.High heat resistance, fast response
2.High reliability and wide range of temperature can be used
3.Various products and complete models
4.Wide temperature range,good stability and high reliability
5.Can provide different both R and B value products with strong interchangeability and high precision
Applications:
1.New energy vehicle charging gun,charging pile
2.Battery temperature monitoring
3.Air conditioning equipment, heating equipment, medical equipment, temperature control instrument, electronic gifts
4.Electronic temperature and humidity meter, automobile temperature measurement, electronic calendar, rechargeable battery pack and charger
Parameters Characteristics：
1.Thermal reaction time: ≤16 seconds in water bath
2.Dissipation factor: about 2.0mW/℃ in standing air
3.Withstanding voltage test：AC 1800V 2mA 1 second
4.Insulation test:≥100MΩ
5.Rated power：≤10mW
6.Operating temperature range：-40℃～125℃
Dimensions:
Ordering instructions：
Please inform the following parameters when ordering NTC temperature sensor:
1、Resistance value requirements (can be selected according to the above table)
2、B value requirements (can be selected according to the above table)
3、Working environment (whether waterproof, moisture-proof, cold and other requirements )
4、Application: different usgae has temperature resistant wire and different resistance value
5、Operating temperature range
6、Accuracy requirement (1%-5% optional)
7、Shell material (copper, brass, stainless steel, ABS, epoxy resin and so on)
8、Customized shell dimensions is welcome
9、Customized wire rod and length is welcome
10、If connectors are needed at the end of the wire(Molex, JST, CJT and others are optional).
We are professional manufacturer of NTC thermistors and temperature sensors. The products are including many parameters
and specifications, please confirm before place an order.
RT table of conventional resistance values：
