Features:
1.Wide resistance range:1KΩ~500KΩ
2.High-thermal conductivity
3.Good insulation, high reliability and stable performance
4.Accept customized
5.Can work stably for a long time (annual resistance drift rate ≤1%)
6.Can be encapsulated according to the installation conditions used
Applications:
1.automobile water and oil temperature
2.Household applicances,rice cooker, heater, soybean milk machine, coffee machine
3.Combustion machine, dishwasher, disinfecting machine, washing machine
4.Automobile temperature control system, medical equipment, communication equipment
Dimensions：
Product Parameters:
Product Features:
1.Thermal reaction time: ≤16 seconds in water bath
2.Dissipation factor: about 2.6mW/℃ in standing air
3.Withstand voltage test:AC 1800V 2mA 1 second
4.Insulation test:AC 1800V≥100MΩ
5.Rated power:≤10mW
6.Operating temperature range：-40℃～150℃
Ordering instructions：
Please inform the following parameters when ordering NTC temperature sensor:
1、Resistance value requirements (can be selected according to the above table)
2、B value requirements (can be selected according to the above table)
3、Working environment (whether waterproof, moisture-proof, cold and other requirements )
4、Application: different usgae has temperature resistant wire and different resistance value
5、Operating temperature range
6、Accuracy requirement (1%-5% optional)
7、Shell material (copper, brass, stainless steel, ABS, epoxy resin and so on)
8、Customized shell dimensions is welcome
9、Customized wire rod and length is welcome
10、If connectors are needed at the end of the wire(Molex, JST, CJT and others are optional).
We are professional manufacturer of NTC thermistors and temperature sensors. The products are including many parameters and specifications, please confirm before place an order.
RT table of conventional resistance values：
