Features：
1. High working temperature（300℃）
2. Under high temperature condition, the material does not change color , crisp and hard.
3. Good stability, high reliability.
4. Scale production, cost-effective
5. Stabilization precision
Applications：
1. Industrial furnace、at high temperature environment、controllable oven、microwave oven、washing machine and dryer, dish-washing machine, household appliances (bread maker)
2. Blunger、hair dryer、curling tongs 、shower、air-conditioner 、stove、refrigerator
3. Electric rice cooker、oven、water-heater、warmer、cooler、water dispenser、disinfection cabinet、washing machine、soybean milk machine
4. Monitor chiller temperature and rechargeable nickel-chromium battery.
Dimensions：
Parameters Characteristics：
1. Withstand voltage test：after 2mA one second, no flashover, breakdown and other abnormal phenomena in the steel ball.
2. Insulation test ：≥100MΩ
3.Operating temperature range：-30℃～300℃ (Head temperature resistance is 300℃，Other parts of the finished product temperature resistant is 250℃)
Ordering Instructions：
Please inform the following parameters when ordering NTC temperature sensor:
1、Resistance value requirements (can be selected according to the above table)
2. B value requirements (can be selected according to the above table)
3. Working environment (whether waterproof, moisture-proof, cold and other requirements )
4. Application: different usgae has different temperature resistant wire and different resistance value
5. Operating temperature range
6. Accuracy requirement (1%-5% optional)
7. Shell material (copper, brass, stainless steel, ABS, epoxy resin and so on)
8. Customized shell dimensions is welcome
9. Customized wire rod and length is welcome
10. If connectors are needed at the end of the wire(Molex, JST, CJT and others are optional).
We are professional manufacturer of NTC thermistors and temperature sensors. The products are including many parameters and specifications,
please confim before ordering. Customized parameters is welcome.
