Features:
1.Good insulation, high reliability, quick response
2.Adopted double-layer sealing process with good insulation sealing, mechanical impact resistance, bending resistance and high reliability
3.Wide temperature range,good stability and high reliability
4.Can provide different both R and B value products with strong interchangeability and high precision
Applications:
1.Automobile/motorbike oil temperature
2.Home air conditioning, car air conditioning
3.Refrigerator, freezer, water heater, water dispenser, heater
4.Dishwasher, disinfecting cabinet, washer, dryer
5.Temperature measurement and control of medium and low temperature drying oven, thermostat and so on.
Dimensions:
Product Parameters:
Product Features:
1.Thermal reaction time: ≤16 seconds in water bath
2.Dissipation factor: about 2.6mW/℃ in standing air
3.Withstand voltage test:AC 1800V 2mA 1 second
4.Insulation test:DC 500V ≥100MΩ
5.Rated power:≤10mW
6.Operating temperature range：-30℃～105℃
Ordering instructions：
Please inform the following parameters when ordering NTC temperature sensor:
1、Resistance value requirements (can be selected according to the above table)
2、B value requirements (can be selected according to the above table)
3、Working environment (whether waterproof, moisture-proof, cold and other requirements )
4、Application: different usgae has temperature resistant wire and different resistance value
5、Operating temperature range
6、Accuracy requirement (1%-5% optional)
7、Shell material (copper, brass, stainless steel, ABS, epoxy resin and so on)
8、Customized shell dimensions is welcome
9、Customized wire rod and length is welcome
10、If connectors are needed at the end of the wire(Molex, JST, CJT and others are optional).
We are professional manufacturer of NTC thermistors and temperature sensors. The products are including many parameters and specifications, please confirm before place an order.
RT table of conventional resistance values：
