Features:
1.High temperature resistance, good water property
2.High accuracy, good consistency and interchangeable both resistance and B value
3.Adopt double-layer sealing process with good insulation sealing, anti-mechanical collision, anti-bending ability and high reliability
4.Can work stably for a long time (annual resistance drift rate ≤1‰)
5.Can be encapsulated according to the use of the installation conditions, easy to install
6.Operating temperature range :-40~250℃.
Applications:
1.Electric kettle, air conditioning equipment, heating equipment, medical equipment, electronic calendar, rechargeable battery pack
2.Temperature control instrument, electronic gift, electronic temperature and humidity meter, automobile temperature measurement
3.Electric rice cooker, oven, water heater, heater, freezer, water dispenser, disinfection cabinet, washing machine, soybean milk machine.
Parameter Characteristics：
1.Thermal reaction time: max 16 seconds in water bath
2.Dissipation factor: about 2.6mW/℃ in standing air
3.Withstand voltage test: 2mA 1min, no flashover, breakdown and other abnormal phenomena in the steel ball
4.Insulation test: in steel ball ≥100MΩ
5.Rated power：10mW
6.Operating temperature range: -40℃ ~ 250℃(the highest service temperature for the head is 250℃, and the highest service temperature for the finished product is 200℃)
Dimensions:
Ordering Instructions：
Please inform the following parameters when ordering NTC temperature sensor:
1. Resistance value requirements (can be selected according to the above table)
2. B value requirements (can be selected according to the above table)
3. Working environment (whether waterproof, moisture-proof, cold and other requirements )
4. Application: different usgae has different temperature resistant wire and different resistance value
5. Operating temperature range
6. Accuracy requirement (1%-5% optional)
7. Shell material (copper, brass, stainless steel, ABS, epoxy resin and so on)
8. Customized shell dimensions is welcome
9. Customized wire rod and length is welcome
10. If connectors are needed at the end of the wire(Molex, JST, CJT and others are optional).
We are professional manufacturer of NTC thermistors and temperature sensors. The products are
including many parameters and specifications, please confim before ordering.
Customized parameters and dimensions is welcome.
RT table of conventional resistance values：
