| Quantity: |
|---|
Features:
1.High precision platinum resistance
2.High temperature resistance
3.Easy to measure temperature environment
4.Good long-term stability
5.Low heat capacity, good reproducibility
Applications:
1.Heater
2.Temperature test for water heater, ice breaker, oven temperature test and barbecue
3.Bread maker, oven, microwave oven,fryer, food processor, water dispenser
4.Electrothermal barrels,electric kettle, coffee pot
5.Soybean milk machine, heater, dishwasher, disinfection cabinet
Parameter Characteristics：
1.Dissipation power coefficient :≥5 mW /℃(in standing air)
2.Maximum rated power :45mW
3.Thermal time constant :≤7S(in standing air)
4.Resistance temperature coefficient: -2 ~ -5%/℃
5.Insulation performance: 500V DC test a single insulation resistance ≥100MΩ
6. Withstand voltage test: 1500V AC，5s，0.5mA, no breakdown
7. Operating temperature：-55℃～150℃
Dimensions:
Ordering Instructions：
Please inform the following parameters when ordering NTC temperature sensor:
1. Resistance value requirements (can be selected according to the above table)
2. B value requirements (can be selected according to the above table)
3. Working environment (whether waterproof, moisture-proof, cold and other requirements )
4. Application: different usgae has different temperature resistant wire and different resistance value
5. Operating temperature range
6. Accuracy requirement (1%-5% optional)
7. Shell material (copper, brass, stainless steel, ABS, epoxy resin and so on)
8. Customized shell dimensions is welcome
9. Customized wire rod and length is welcome
10. If connectors are needed at the end of the wire(Molex, JST, CJT and others are optional).
We are professional manufacturer of NTC thermistors and temperature sensors. The products are
including many parameters and specifications, please confim before ordering. Customized parameters and dimensions is welcome.
RT table of conventional resistance values：
